GEDA
®
Temporary Construction Hoist PH 650
Operating Manual Page 13 of 64 BL148GB2017 / 11
3.2 Speeds
Lifting speed
Operation
40 m/min.
131 ft/min.
60 m/min*)
196 ft/min
65 m/min.
213 ft/min.
90 m/min.
295 ft/min.
*) USA
Triggering speed of safety gear:
Drive
40 m/min.
131 ft/min.
60/65 m/min.
196/213 ft/min.
90 m/min.
295 ft/min.
Releasing
speed:
Approx. 48 m/min.
Approx. 78 m/min.
Approx. 108 m/min.
Approx.157 ft/min.
Approx. 256 ft/min.
Approx. 354 ft/min.
Gravitational acceleration
in the car with EMERGENCY OFF < 1 g
3.3 Drive
Technical information about the drive: refer to nameplate of the drive
3.4 Lifting capacities
Ladder in the car max. 330 lb (max. 150 kg)
3.4.1 GEDA PH 650 with car PH 2032
Operation 4400 lb (2000 kg) /
max. 25 persons
3.4.2 GEDA PH 650 with car PH 2737
Operation 6000 lb (2700 kg) /
max. 28 persons
3.4.3 GEDA PH 650 with car PH 3240
Operation 7055 lb (3200 kg) /
max. 30 persons
