Temporary Construction Hoist PH 650
Operating Manual Page 43 of 64 BL148GB2017 / 11
10.3.7 Car doors
Vertical sliding door
 Carefully fully open or close the door in the
centre of the plate.
Vertical sliding door with ramp

Must not be used:
• in USA (ANSI A10.4) and Australia (AS 1418.7).
• in other countries / states, in which the standards ANSI A10.4
and AS 1418.7 are applicable.
• For hoists with an operating speed of more than 42 m / min.
Opening from the inside:
 Carefully open or close
the door in the centre of
the plate.
Ramp automatically
rises/lowers.
Opening from the
outside:
 Open door using the
handle (2).

The ramp must safety rest on the landing floor and transition plate of
the landing level safety door.

The handle must be installed on the left or right depending on the
location of the landing door.
2
