Temporary Construction Hoist PH 650
Operating Manual Page 32 of 64 BL148GB2017 / 11
9 Brief description of the hoist
WARNING
This brief description only presents a general overview of
the hoist. It does not form the basis for correct and proper
operation of the hoist by beginners. Operation of the hoist
and training of personnel is always carried out with
reference to the detailed descriptions in the appropriate
section of this manual.
Enclosure (1)
The bottom stop position is
provided with an enclosure. The
enclosure prevents access to the
bottom hazard area. The car can
only be accessed through the
landing level safety gate and door
to the car.
Landing-level safety doors
Landing doors protect people from
falling at the stop position when
the car is not at that stop position.
Car doors (2)
The car doors protect the persons
in the car from falling out of the car
during transportation.
SINGLE / TWIN design
By using a GEDA mast system with two gear racks and a corresponding
base enclosure, the hoists can be operated both as Single (one car on the
mast) as well as a Twin (two cars on the mast.
