Temporary Construction Hoist PH 650
Operating Manual Page 36 of 64 BL148GB2017 / 11
10.3 Normal mode
10.3.1 Control in the car – Stop Next Landing
1 = Car emergency lighting
2 = EMERGENCY STOP
3 = Control light, ready for service
4 = Overload warning light
5 = Stop Next Landing (SNL) Stop at next landing level
6 = UP button
7 = DOWN button
8 = STOP button - stop at the current position
10.3.1.1 Operation
Ascend
 Press the UP button.
Descend
 Press the DOWN button.
Stop Next Landing
Stop at the next landing above
 Press the UP button.
 Press button "Stop Next Landing" (5).
Button "Stop Next Landing" illuminates. The car only moves slowly and
stops at the next landing above.
Stop at the next landing below
 Press the DOWN button.
 Press button "Stop Next Landing" (5).
1
6
4
5
3
2
7
8
