GEDA
®
Temporary Construction Hoist PH 650
Operating Manual Page 57 of 64 BL148GB2017 / 11
Significance of the symbols and number codes
Display
Explanation

Ascend

Descend
01
Actual position
ERROR 03
Door "A" open
ERROR 04
Door "B" open
ERROR 05
Door "C" open
ERROR 06
Door "D" / "E" open
ERROR 07
Enclosure door open / setting mechanism activated
ERROR 08
EMERGENCY STOP line of the ground station is
interrupted
(EMERGENCY STOP ground station, landing-level safety
door control or dummy plug)
ERROR 10
EMERGENCY LIMIT UP car moved too high
ERROR 11
EMERGENCY LIMIT UP climbing formwork
ERROR 12
EMERGENCY LIMIT DOWN car moved too low
ERROR 13
EMERGENCY LIMIT DOWN climbing formwork
ERROR 14
Safety gear has triggered
ERROR 15
Roof hatch open
ERROR 16
Assembly bridge Roof 1 (extended)
ERROR 17
Assembly bridge Roof 2 (extended)
ERROR 20
EMERGENCY STOP ground station
ERROR 21
EMERGENCY STOP car control
ERROR 22
EMERGENCY STOP roof switch box
ERROR 23
Assembly / drop test control active
ERROR 25
EMERGENCY STOP landings
ERROR 26
EMERGENCY STOP buffer / dummy plug
ERROR 27
EMERGENCY STOP Dummy plug roof
ERROR 30
Car overloaded
ERROR 31
Interlock cam (activating rail is extended)
ERROR 32
Underrun protection, cable carriage
(collision car with cable carriage)
ERROR 33
Wind sensor (excessive wind)
ERROR 34
Cold package (temperature < -20 °C / -4°F)
ERROR 35
Motor temperature excessive
ERROR 36
Temperature braking resistance too high
ERROR 37
Frequency inverter fault
ERROR 38
Lubrication device: lack of grease
ERROR 39
No mains voltage
ERROR 40
Battery charging fault
ERROR 41
Fuses -3F002 - -3F300 (in the roof switch box)
ERROR 42
Assembly crane (disconnection open)
ERROR 47
Fault in lubrication device "malfunction"
ERROR 48
Monitoring motor brake
ERROR 49
Car control not connected
