OptiCenter OC06 Maintenance / Repairs
79
15. The process step is complete when the key looks like this.
The key can be pressed once again if necessary. This is a sign that
the next cleaning step will be activated.
16.
17. The OptiSpeeder is cleaned, the powder from the OptiSpeeder is
transported to the booth
18. The powder is conveyed from the booth
19. The process is complete once this symbol is displayed
(after approx. 180 seconds for intensive cleaning and approx. 30
seconds for quick cleaning).
20.
– The powder hoses are cleaned and the powder is transported to
the booth
– The powder is conveyed from the booth
