Page 163
DISASSEMBLY
PART 6
Section 6.1
Major Disassembly
ITEM QTY. DESCRIPTION
1 2 WASHER LOCK M6-1/4
2 2 SCREW HHC M6-1.0 X 30 C8.8
3 3 SCREW HHFC M5-0.8X12 W/PATCH
4 1 BRACKET CUSTOMER CONNECT
5 2 WASHER FLAT M6
6 2 NUT HEX M6 X 1.0 G8 YEL CHR
7 1 COVER CUSTOMER CONNECT
8 3 SCREW HHFC M6-1X12 8.8 W/PATCH
9 2 SCREW HHSP #10X3/8 HI-LO
10 4 SCREW HHC M4-0.7 X 25 SEMS
11 2 GROUND BAR
12 2 SCREW PPHM M3-0.5 X 12 SEMS (8kW)
4 SCREW PPHM M3-0.5 X 12 SEMS (10kW,
13kW, 14kW, 16kW, 17kW, & 20kW)
13 1 CB BRACKET CONTROL BOX
14 1 RELAY 12V 25A SPST (10kW, 13kW, 14kW,
16kW, 17kW, & 20kW)
15 2 SCREW PPHM M3-0.5 X 30
16 1 ASSY PCB TRIP LED DISPLAY
17 1 CB 0015A 1P 120V S BQ1 LB (16kW,
17kW & 20kW)
18 3 SCREW HH HI-LO M4X10MM (16kW,
17kW & 20kW)
1 SCREW HH HI-LO M4X10MM (8kW, 10kW,
13kW, & 14kW)
ITEM QTY. DESCRIPTION
19 2 SCREW REDUCED HH HI-LO M6X10MM
20 1 BLOCK TERM 5POS 20A
21 1 TERM BLOCK 3P UL 12-20AWG
22 1 EYE HASP CNTRL PANEL
23 1 ASSY CONTROL BOX (8kW, 10kW, 13kW,
& 14kW)
24 2 PLUG PLASTIC DOME 7/16"
25 1 OUTLET, 15A GFCI DUPLEX WHITE (16kW,
17kW & 20kW)
26 1 CB 0035A 2P 240V S BQ2 LB (8kW)
1 CB 0045A 2P 240V S BQ2 LB (10kW)
1 CB 0055A 2P 240V S BQ2 LB (13kW)
1 CB 0060A 2P 240V S BQ2 LB (14kW)
1 CB 0065A 2P 240V S BQ2 LB (17kW)
1 CB 0100A 2P 240V S BQ2 LB (20kW)
27 1 CAP LOCKOUT
28 REF FUSE, ATO TYPE 7.5AMP (BROWN)
29 1 ASSY CNTR PROGRAMMED
30 1 HARNESS (NOT SHOWN)
