Page 34
PART 1
GENERAL INFORMATION
Section 1.9
Wireless Remote
4. Remove the large enclosure panel from the front of the
enclosure.
5. Locate the radio connector under the generator display
panel. It is the closest one to you as you are facing the
generator; it has a white connector with gray cable going
to it. It has a locking tab that needs to be squeezed to
remove it. Remove the connector by squeezing the tab and
pulling the connector down. As the locking mechanism is
a tight fit, you may need pliers to help release it.
6. Turn on the display unit and go to the RADIO menu.
7. Select “RESET RADIO” and IMMEDIATELY (within 5
seconds) put the connector back into the controller (that
you removed in step 5E).
8. The display unit will start searching for the generator.
Up to one minute will pass while the remote unit and
generator synchronize. Once the generator is found, the
radio link has been re-established and the settings will be
remembered.
9. Re-fit the front enclosure panel and close the lid.
10. Turn the Auto/Off/Manual switch to the Auto position.
11. Return the display unit to its original location and
re-connect it to the wall transformer. Turn it off and back
on again (this is just to get it out of sleep mode which it
may have entered on battery power).
Results
1. If the link is established, discontinue troubleshooting.
2. If the link fails to establish, repeat Steps 5-8 using a
different channel.
3. If the link continues to fail, replace the wireless remote and
transmitter.
