Page 87
d. Connect one meter test lead to T1 on the customer
connection in the Generator and the other meter test
lead to Wire N1. Measure and record the resistance.
e. Connect one meter test lead to T1 on the customer
connection in the Generator and the other meter test
lead to Wire N2. Measure and record the resistance.
Results
1. If the VOM indicated INFINITY in Steps 4a -4e, replace the
controller.
2. If the VOM indicated CONTINUITY, repair or replace the
wiring in the appropriate circuit.
TRANSFER SWITCH
PART 3
Section 3.4
Diagnostic Tests
