Genetec AutoVu SharpX Mobile - Camera Connections for the X2 S LPR Processing Unit

AutoVu SharpX mobile installation
tip.genetec.com | AutoVu Hardware Guide for SharpX Mobile Installation
EN.410.018-XS(6) | Last updated: October 6, 2016 30
Camera connections for the X2S LPR Processing Unit
Each camera port on an X2S LPR Processing Unit has its own dedicated hardware path. You can
connect XGA or VGA SharpX cameras to any port without a loss of frame rate.
X2S LPR Processing Unit
Camera
port 1
Camera
port 2
Camera
port 3
Camera
port 4
Hardware
path 4
Hardware
path 3
Hardware
path 1
Hardware
path 2
SBC 2
SBC 1
