Troubleshooting for SharpX mobile installation
tip.genetec.com | AutoVu Hardware Guide for SharpX Mobile Installation
EN.410.018-XS(6) | Last updated: October 6, 2016 74
System status LEDs on the LPR Processing Unit
The LPR Processing Unit displays system status LEDs.
The following table describes how the LEDs behave in response to the SharpX system’s status. The
headings PWR, STAT 1, STAT 2, AND FAULT correspond to the LEDs on the LPR Processing Unit.
State Description PWR STAT 1 STAT 2 FAULT
Off Unit powered off Off Off Off Off
Reflash The unit has failed
an integrity test
on the contents of
the control board
flash memory. It is
waiting for a reflash
to be performed
over the network.
On On Off Off
POST Power-on self-
test. All LEDs flash
in sequence and
then together for
approximately
three seconds at
power-up, if the
control board flash
memory has passed
validation.
See
description
See
description
See
description
See
description
Get DHCP The unit is waiting
for a DHCP lease
over the network
(it is configured
in “external DHCP
mode”).
On 5 quick
flashes then
pause, every 3
seconds
Off Off
Thermal
Shutdown
The internal
temperature
is outside the
operational limits.
Power is no longer
supplied to most
components. No
Ethernet network
connectivity is
possible.
Toggles
once per
second
Off Off Toggles once
per second
Power Fault A fault was detected
on the main power
source.
Toggles
once per
second
Off Off On
