Camera data-link status LEDs on the LPR Processing Unit
The LPR Processing Unit displays data-link status LEDs.
The following table describes how the Data-Link LEDs behave in response to the SharpX system’s
status.
State Description Data (amber) Link (green)
Data idle No Ethernet data
is being received/
transmitted between
the camera and the
trunk unit.
Off N/A
Data transmit Ethernet data is being
received/ transmitted
between the camera
and the trunk unit.
Blink N/A
Not registered The camera is not
registered with the
trunk unit yet. It may
take up to 30 seconds
for a camera to be
registered.
N/A Off
Registered The camera is
registered with the
trunk unit, and can
exchange control
messages with the LPR
engine.
N/A On
