About installing wheel imaging cameras in a mobile AutoVu
system
Wheel imaging cameras are required for digital tire chalking in City Parking Enforcement installations
that include wheel imaging.
When comparing wheel images from Patroller's first pass and second pass, you can use the wheel's
valve stem (or other reference point) to see whether the wheel has moved a short distance.
To accurately record the wheel images, the system requires the use of either the Navigator box or an
LPR Processing Unit with the AutoVu Navigation Option. This will allow the system to interface into
the vehicles odometer signal to know the distances traveled.
Camera specifications
• 6 mm lens
• Built-in IR LEDs
• Automatic heating when the temperature is below +10°C (50°F)
• Waterproof housing (IP67)
Required tools and parts
The following tools and parts are required for wheel imaging camera installation:
• Allen wrench (included)
• Phillips screwdriver
• 7 mm socket/key wrench
• Drill
• 4.7 mm (3/16”) drill bit
• 19 mm (3/4”) hole saw
NOTE: Use a fine-toothed hole saw that is designed for vehicle body panels (should be depth-
regulated and include a pilot drill bit). Do not use a stepping bit because it will deform the panel.
• Tie wraps for securing cable
• Additional cable glands (grommets)
Example
Watch this video to learn more. Click the Captions icon (CC) to turn on video captions in one of the
available languages.
