G-858BP Backpack Mag Operators Manual
Power Connector
Download Connector
Sensor 1 Connector
Sensor 2 Connector
Figure 5 G-858 Connector Set
Assembly of the Pack Frame components
Remove the console from the special pocket enclosure, lift the Pack Frame and console free of the
shipping container and set them on a table or clean surface. Remove the Sensor from its storage pocket in
the front of the case and attach it to the front connector (Channel 1). See the picture below with the sensor
cable and power cable are attached to the Console. They may have been removed during storage.
8
