G-858BP Backpack Mag Operators Manual
Chapter 3: Console and GPS Operation
G-858BP Console Operation
The G-858BP console is pictured below. The slots in the spreader bar are designed to slip over the
console belt. The holes are for attaching the front vertical shoulder straps. The connectors are for the
power cable and I/O port (RS-232). The cesium sensor is hard wired into the console.
The upper left connector is the battery connector, the upper right is the serial I/O port, and the
lower cable is a non-removable connection for the sensor. Note spreader bar attached to the bottom of the
console. This bar attaches the console to the Console Belt and the Console Support Straps.
Channel 1 Sensor
Connector
RS-232 Port
Connector
Power Connector
Channel 2 Sensor
Connector
24
