G-858BP Backpack Mag Operators Manual
MARK: 10
PRESS ANY KEY TO CLEAR THIS MESSAGE
THEN PRESS "MARK" TO START NEXT LINE
OR
PRESS "MENU" AND SELECT
"EDIT LINE AND MARK"
FOR EDITING
To start the next line, you must first press any key to clear this dialog box, then press MARK as
you start walking up the next line. We encourage you to look at this line summary between lines, to make
sure you are where the unit thinks you are, and the last line has the right number of mark key presses. If
there is a problem at this point, you may edit the most recently taken data. You are not able to edit any
except the most recently acquired data.
Note: Don’t forget the key press necessary to clear the dialog box. The END
LINE key is handy for this since it was the last key pressed. If you forget to
clear the dialog box, the next MARK key press will not start data acquisition
(it will only clear the dialog box).
Adjust Menu
Pressing the MENU key from the Acquisition Display will bring up the adjust menu. This allows
you to adjust the display and audible tones, and to enter the data editing menu.
SIMPLE
SURVEY
Field:
49953.1
!ACQUIRE!
QC:
0.33
Scale:
50
S-232 in: R
e: Lin
0
k: Mar
0
aster volume: < 4 > M
Woowee:
Volume: < 4 >
Sensitivity: < 4 > Hz/nT
QC warning
Volume: < 4 >
Level: [ 9.999 ] nT
ull scale: < 50 > nT F
dngs/screen: < 25 > R
EDIT LINE AND MARK
CENTER TRACE
Simple Survey Adjust Menu.
Master Volume
Adjusts the over-all volume. 1 is softest, 9 loudest.
Woowee Volume
1 is softest, 9 loudest
Woowee Sensitivity
40
To Next Page
