G-858BP Backpack Mag Operators Manual
Chart Display
The chart display varies slightly depending upon whether the survey is a simple survey, mapped
survey, or base station.
4.00
0.00
4.00, 0.75
Coordinate of to
p
of dis
p
la
y
Coordinate of bottom of dis
p
la
y
Cursor
Cursor line number
Cursor mark coordina
t
Chart Display for Simple Survey
100.00
0.00
0.00, 50.00
Coordinate of top of display
Cursor x,y coordinate
Coordinate of bottom of display Cursor
Chart Display for Mapped Survey
70
