G-858BP Backpack Mag Operators Manual
Acquire Menu
Pressing the MENU key will bring up the acquire menu.
--- ACQUIRE MENU ---
Next X = 24.00
Next Y = [ 100.00 ]
Current Direction < DOWN >
Full scale: < 50 > nT
< 25 > Readings per screen
EDIT LINE AND MARK
Cycle Time [ 0.2 ] S
Next X
Next Y
You may change position along the line you are on. Depending on the direction of your survey,
you will be allowed to enter a number into one of these two fields. This is very useful when your path is
blocked. See the later section “Advanced Features” for more information on using this feature.
If you are between lines, you will be allowed to adjust both of these numbers. You cannot,
however, enter a line position which isn’t on the regular grid. To do that, you must re-define the grid. See
the section on Multi-Grid Surveys.
Note: You may also change the next position by pressing the arrow keys
directly from the acquisition display after an END LINE key press.
Current Direction
You may toggle between up and down.
Full scale
The scale width of the sweep display, in nT.
Readings per screen
The vertical scale, or sweep rate on the display.
EDIT LINE AND MARK
Brings up the editing menu, see below.
Pressing ESC will return the unit to the acquisition display.
