G-858BP Backpack Mag Operators Manual
Chapter 4: Search Mode
Search Mode
In search mode, the magnetometer operates normally, displaying data and the woowee audio
tones, but data is not stored in memory. This is useful for manually identifying anomaly locations, much as
with a metal detector. It is also useful for checking for proper sensor operation and ambient magnetic
noise.
Select SEARCH MODE from the main menu. You should see a display similar to that below:
SEARCH
MODE
Field:
45674.23
DATA NOT
STORED
QC:
0.09
Scale:
50
Adjust:
"MENU"
Example of Search Mode Display
Note: Data is not stored in Search Mode. This is indicated on the display, so
you do not confuse it with Simple Survey.
Search Mode Adjust Menu
Pressing the MENU key will bring up the Search Mode Adjust Menu. This allows you to adjust
the display and audible tones:
SEARCH
MODE
Field:
49953.1
DATA NOT
STORED
QC:
0.33
Scale:
50
ADJUST:
“MENU”
aster volume: < 4 > M
Woowee:
Volume: < 4 >
Sensitivity: < 4 > Hz/nT
QC warning
Volume: < 4 >
Level: [ 9.999 ] nT
ull scale: < 50 > nT F
dngs/screen: < 25 > R
ycle Time [ 0.2 ] s C
CENTER TRACE
34
