GeoVision GV-VS12 User Manual

8.2 VSM
The VSM is designed to monitor and manage the cameras and I/O devices connected to
the GV-Video Server under low bandwidth network.
GV-Video Server
GV-Video Server
TCP/ IP
X 4
X 4
VSM
Text Data
X 4
X 4
Figure 8-4
¾ To set the appropriate port connecting to the GV-Video Server, click Configure on the
window menu, and select System Configure to display this dialog box. In the
Connective Port field, keep the default value 5609 for the Port 2 option, or modify it to
match the VSM port on the GV-Video Server.
Figure 8-5
For further information on how to mange the video received from the GV-Video Server,
see GV-CMS Series User’s manual.
134

GeoVision GV-VS12 Specifications

General

Brand	GeoVision
Model	GV-VS12
Category	Server
Language	English
