Introduction
1–8
BYPASS SWITCH
MP-129 The toggle switch on Water-Saver I/F Box 47A permits hospital
maintenance or Getinge USA service personnel to switch off the water-
saver as a vacuum source and use the sterilizer’s standard ejector with
external water supply.
Figure 1–5. BYPASS SWITCH (MP-129 Only)
MP-129F The water-saver can be turned off from the display panel on the sterilizer.
The Water Saver configuration switch (DS14) is located on the
DIPSWITCHES branch of the SERVICE menu tree. Refer to the sterilizer
Service Manual for instructions on how to navigate the menu tree.
MANUAL DRAIN VALVE
Located in the feed water line to the pump, this manual valve permits easy
draining of the water-saver reservoir when required.
Bypass
Switch
Water Saver
I/F Box 41A
