MP–129F Water-Saver
350545 3–3
MP-129F INSTALLATION SEQUENCE
Turn off all electricity, water, and steam to the sterilizer before
starting the water-saver installation. Touching live electrical
connections and/or exposure to live steam could cause serious
injury.
Installation of the water-saver consists of:
1. Locating, mounting, and anchoring (page 3-4).
2. Modifying the sterilizer piping (page 3-5).
3. Connecting the cold water supply (page 3-5).
4. Connecting the overflow drain line (page 3-6).
5. Connecting the electrical cables (page 3-7).
6. Checking the rotation of the pump motor (page 3-9).
Refer to the engineering drawings listed in Table 3–1 during
installation of the MP-129F Water-Saver.
WARNING
Table 3–1. MP-129F Water Saver Drawings
Sterilizer Model Piping Package Piping Schematic Wiring Diagram
400/500 Series
700 Series
800 Series
61301609273 PI0022 W1320
