Getinge MP-129 Series - Package Contents

MP-129 Installation
2–2
PACKAGE CONTENTS
MP-129A Assembly 61301602997 (Rev. C)
MP-129B Assembly 61301602998 (Rev. A)
MP-129C Assembly 531185 (Rev. D )
MP-129D Assembly 531186 (Rev. C)
MP-129A,3500/100,WATER SAVER
Item Description Part Number Qty
1 MANUAL(U)-WATER SAVER 350545
1
2 CASTLE,WATER SAVER SYS HS03472
1
3 WATER SAVER PKG,1.25ID,120V 531167
1
4 PIPING PKG,100/MC3500,WTR SVR 61301603246
1
5 SCH,PIPING,SPCL OPTION P1925
1
6 CONT PKG,WTR SVR,PACS/MC,120V 61301603222
1
7 DIAG,WIRING,WTR SVR,PACS/MC W1297
1
MP-129B,3600/200,WATER SAVER
Item Description Part Number Qty
1 MANUAL(U)-WATER SAVER 350545
1
2 CASTLE,WATER SAVER SYS HS03472
1
3 WATER SAVER PKG,1.25ID,120V 531167
1
4 PIPING PKG,233/MC3633,WTR SVR 61301603247
1
5 SCH,PIPING,SPCL OPTION P1925
1
6 CONT PKG,WTR SVR,PACS/MC,120V 61301603222
1
7 DIAG,WIRING,WTR SVR,PACS/MC W1297
1
MP-129C,4200(42),WATER SAVER
Item Description Part Number Qty
1 MANUAL(U)-WATER SAVER
350545 1
2 CASTLE,WATER SAVER SYS
HS03472 1
3 WATER SAVER PKG,1.25ID,120V
531167 1
4 PIPING PKG,MC4233(76"") WTR SVR
531174 1
5 SCH,PIPING,MC4233,W/WTR SAVER
P1781 1
6 CONT PKG,WATER SAVER,120V
531175 1
7 DIAG,WIRING,WATER SAVER,MC----
531181 1
MP-129D,4200(76),WATER SAVER
Item Description Part Number Qty
1 MANUAL(U)-WATER SAVER 350545
1
2 CASTLE,WATER SAVER SYS HS03472
1
3 WATER SAVER PKG,1.25ID,120V 531167
1
4 PIPING PKG,MC4233(76"") WTR SVR 531174
1
5 SCH,PIPING,MC4233,W/WTR SAVER P1781
1
6 CONT PKG,WATER SAVER,120V 531175
1
7 DIAG,WIRING,WATER SAVER,MC---- 531181
1
