Getinge MP-129 Series - Overflow Drain

MP-129F Installation
3–6
Overflow Drain Connect a drain line to the 1¼" female pipe thread fitting on the overflow
drain port on the side of the water-saver reservoir. Connect the manual
drain valve to the same drain line.
Figure 3–2. DRAIN CONNECTIONS
Overflow
Drain Outlet
Manual
Drain Valve
Water Saver
Drain Outlet
350545-AF
