Control Word 2
Control Word 2 defines the commands relating to management of the supplementary
functions of the steppers, and of accessory functions.
Bit Description
0 Reset stepper gun 1
1 Reset stepper gun 2
2 Reset stepper gun 3
3 Reset stepper gun 4
4 Reset stepper gun 5
5 Reset stepper gun 6
6 Reset stepper gun 7
7 Reset stepper gun 8
8Not used
9Not used
10 Not used
11 Not used
12 Not used
13 Start log
14 Stop log
15 Reset communication fault
Control Word 2 -Functional description
Bit Signal Function
0/7
Reset gun 1
÷
÷÷
÷
8
stepper
Bit = 1.
Reset gun no. stepper recognized.
Information that “stepper counters no.s reset” is
confirmed (see specific description at para. 14.2).
8/12 -
Not used.
13 Start Log
Data storage for the protocol function for test pieces
begins.
14 Stop Log
Data storage for the protocol function for test pieces
stops.
15 Reset
Communication
Fault
Communication fault alarm is reset (Status word 2 –
bit 15).
