Weld334m - User’s manual
InterBus-S Profil F-IBS/03
62
Control Word 3
Control Word 3 defines the Spot Index.
The Spot Index is an index (that can be defined from 1 to 65535) used to select a welding
spot contained in a database specifically created and managed through tne FASE
SALDATURA WMS centralisation program.
Each Spot Index in this database is associated to a working name (generally the name of
the spot to be welded) and a reference to the welding program that must be performed.
In each welding control, the necessary part of the database is saved through the WMS
centralisation program.
Signals sent by the Weld334m on the welding status, (diagnostics, program called up,
electrode pressure, etc.) are integrated with a Spot Index value and the name of the
welding spot.
WARNING
If there is no specific parameter setting, where a program code value
different from zero (Control Word 1 bit 8-13) and a Spot Index value
different from zero (Control Word 3 bit 0-15) appear, the welding
control will perform the selected sequence with the program code.
Bit Description
0 Spot index selection bit 0
1 Spot index selection bit 1
2 Spot index selection bit 2
3 Spot index selection bit 3
4 Spot index selection bit 4
5 Spot index selection bit 5
6 Spot index selection bit 6
7 Spot index selection bit 7
8 Spot index selection bit 8
9 Spot index selection bit 9
10 Spot index selection bit 10
11 Spot index selection bit 11
12 Spot index selection bit 12
13 Spot index selection bit 13
14 Spot index selection bit 14
15 Spot index selection bit 15
For further information, please see the WMS manual.
