Omnia PCB Omnia Web Pages
Page 5-34 MDE-5369E FlexPay™ IV (with Omnia) Programming and Service Manual · April 2020
Figure 5-51: General Settings for GENERIC CRIND Connection Type
The following table provides details to select an appropriate Internal CRIND IP address for
the associated fueling position:
Note: After changing general settings while Idle loop is playing, an Omnia reboot is needed
to restore Applause Multimedia System functionalities. For more information, refer to
“Reboot” section on page 5-43
Internal IP Scheme FlexPay IV
Fueling
Position Side
CRIND IP
Address
Default
Gateway
1/2
A 172.20.100.1 172.20.100.254
B 172.20.100.3 172.20.100.254
3/4
A 172.20.100.1 172.20.100.254
B 172.20.100.3 172.20.100.254
Card
Reader
N/A 172.16.100.2 172.16.100.1
Etc. Etc Etc. Etc.
Note: The table shows IP addresses that FlexPay IV
automatically assigns as internal IP address based
on the detected Side (A/B).
