2.4.3.1. PI 4xCL
Pin Channel Description Comm. Interface Comm. Type
1 CH1 C.L. (+) EXT1 RS-232
2 CH1 C.L. (-) EXT1 RS-232
3 CH1 Logic GND EXT1 RS-232
4 n.c. n.c.
5 CH2 C.L. (+) EXT2 RS-232
6 CH2 C.L. (-) EXT2 RS-232
7 CH2 Logic GND EXT2 RS-232
8 n.c. n.c.
9 Protection Earth
Table 2-13 - PI4xCL-CN1
Pin Channel Description Comm. Interface Comm. Type
1 CH3 C.L. (+) EXT3 RS-232
2 CH3 C.L. (-) EXT3 RS-232
3 CH3 Logic GND EXT3 RS-232
4 n.c. n.c.
5 CH4 C.L. (+) EXT4 RS-232
6 CH4 C.L. (-) EXT4 RS-232
7 CH4 Logic GND EXT4 RS-232
8 n.c. n.c.
9 Protection Earth
Table 2-14 - PI4xCL-CN3
OrPAY1000 Installation and Setup Manual 11
