2.4.3.2. PI 2xCL
Pin Channel Description Comm. Interface Comm. Type
1 CH1 C.L. (+)
2 CH1 C.L. (-)
3 CH1 Logic GND
4 n.c. n.c.
5 CH2 C.L. (+)
6 CH2 C.L. (-)
7 CH2 Logic GND
8 n.c. n.c.
9 Protection Earth
Table 2-15 - PI2xCL-CN1
Figure 2-7 - CurrentLoop Board
12 OrPAY1000 Installation and Setup Manual
