Figure 5-21 - Channels Setup Tab
Click Add Channel to add a channel to the converter. The following is added (see Figure 5-22):
Figure 5-22 - Add Channel
The following additional actions are available:
Click Add Channel to add another channel
Click Remove Channel to remove the last channel from the list
Click Copy Channel to add another channel with the same settings as the last channel on the list
Define the channel fields (see Table 5-6):
Click on the Submit button to save the changes locally
Note: Clicking on Submit only saves the configuration temporarily on a local level. To
commit the changes permanently, make sure to save everything via the Save tab.
Field Description
Host Interface
TCP/IPPort Host TCP/IP Port
Table 5-6 - Channels Setup Fields
OrPAY1000 Installation and Setup Manual 50
