GKB 4CH/8CH VFire Server
16
cameras in any available split window format.
n Hard disk drive
Make sure to install at least one SATA hard disk (Max. storage size >4TB) inside
the NVR. The steps are as below:
1. Power off the machine, and then use
a screwdriver to uncover it.
2. Connect the cables.
3. Hold the SATA HDD, and use a
screwdriver to fix it.
4. Cover the machine.
Note 1: The HDD must be formatted before it can be used to record
video/audio. Please refer to Section 6.6.1 to format the HDD.
n Power
Connect DC 12V power source to DC 12V. For PoE models, please also
connect DC 48V power source to DC 48V.
