GKB 4CH/8CH VFire Server
79
7. PTZ Control
The network video/audio recorder supports a variety of PTZ cameras. The user
can easily control the PTZ cameras through the operations described in this
Chapter if those PTZ cameras have been connected and setup correctly. Please
refer to Section 6.1 Pre-Camera Setup to set the camera as a PTZ camera.
If a camera is also a PTZ camera, there will be an asterisk (*) preceding its title in
its video window in split-window display. Please press PTZ button (Mouse: )
to enter PTZ control mode if the focus camera is a PTZ camera. The asterisk (*)
will be changed to inverse color to indicate that the camera is now in PTZ control
mode.
In PTZ control mode, the user’s operations can be divided into general operations
and miscellaneous function specific operations, and are described as the
followings:
General operations:
n PTZ (Mouse: )
Press this button to exit PTZ control mode. The asterisk (*) will be changed
back to normal color.
n ▲▼ (Mouse: Left-click in the up/down area of the video window)
Press these buttons to tilt the camera up/down.
n ◄► (Mouse: Left-click in the left/right area of the video window)
Press these buttons to pan the camera left/right.
n ZOOM ( ) +/- (Mouse: )
Press these buttons to zoom in/out the camera.
n GOTO (Mouse: )
Press this button to move the camera to the preset position. Press numeric
buttons 0-9 to enter the number of the preset position to move the camera to.
The range of the preset positions is 00-254.
n NEXT
Press this button for the next miscellaneous function. The miscellaneous
functions include Focus, Iris, Auto PAN, SEQ, Preset, and Pan Speed. And the
active one will be shown on the lower right corner of the screen. The
