GKB 4CH - 6.2 Camera Setup

GKB 4CH/8CH VFire Server
37
6.2 Camera Setup (Please refer Appendix G for Flame/Smoke detection)
In Setup Menu display, press ▲▼◄► to change the highlighted option to
Camera, and then press ENTER (Mouse: Left click) to call up Camera Setup display.
The Camera Setup allows the administrator to define the attributes for each
camera. There are up to 8/4 IP CAM, which can be connected to the system.
The general operations are as below:
n ▲▼◄► (Mouse: Left click)
Press these buttons to select the items. The display will scroll left/right if the
selected item is not shown on the screen.
n Numeric
Press these buttons to select the camera.
n COPY ( )
Press this button to copy all the settings - excluding detailed Motion settings,
Video Loss settings, Title/Audio - of the focus camera to all the following
cameras. (EX. focus camera is 1, its settings will be copied to those of
cameras 2-8/4.)
n ESC (Mouse: Right Click)
Press this button to escape from this screen, and return to Setup Menu display.
If the Save dialog is shown, press ENTER to exit and save, ESC (Mouse: Right
Click) to exit without saving.
