GMC-I Messtechnik GmbH 11
4.3 Device Settings
For the purpose of initial start-up, we recommend
setting the following basic parameters in the order
shown at the right:
Setup 2/3 > Culture > Language (for user interface)
Setup 2/3 > Culture > Keyboard Layout (for alphanumeric entries)
Setup 1/3 > System > Date / Time (for report generation)
Setup 1/3 > System > Brightness (display brightness as %)
Setup 1/3 > Auto Measurements
> 2/2 > Initial Window Style: Tree or Detail View
Figure 2 Device Settings, Main Menu Level – SETUP Switch Setting
The following parameters are advisable for maintenance purposes:
SETUP 3/3 > Test > Display / Buzzer (for checking info and warning
displays/signals)
SETUP 3/3 > System Info > Software Version for updates (see sec-
tion 13.3) and Calibration Data for adjustment, last and next calibra-
tion (see notes on bottom of page 12).
See section 13.3 regarding downloading the latest software version.
Notes Concerning the Inspector Parameter
– The inspector who has just been “selected” appears in tests
to be conducted as “Inspector”. None of the SECUTEST set-
tings are stored specifically for the inspector – all settings in
the SECUTEST are stored for the respective device and are
available to all inspectors.
–
If an inspector is password-protected
, this only prevents users who don’t
know the password from “selecting” this inspector. There’s
no
pass-
word prompt when the test instrument is started up.
The inspector
remains selected even in the event of a power failure – a
(password-protected) inspector can only be unselected by
selecting another inspector.
As of firmware 1.6.0: In order to delete an inspector whose
password you don’t know, it’s sufficient to enter an incorrect
password five times in a row and to confirm the entry each
time – a query then appears as to whether or not the inspec-
tor should be deleted. The inspector to be deleted may not be
the same as the currently selected inspector.
Display additional menu pages
Menu selection for operating parameters, page 1 of 3
Clear database or display statistics,
Set date/time, volume, and brightness
Display additional menu pages
Menu selection for operating parameters, page 2 of 3
Add, select, delete or protect inspector
Select language for user interface and keyboard
For example, select and configure barcode scanner
Display additional menu pages
Menu selection for operating parameters, page 3 of 3
(see submenu on following page)
Keys with fixed functions
Softkeys = keys with functions that vary
depending on the operating level
PRINT
ESC
HELP
MEM
PRINT
ESC
HELP
MEM
PRINT
ESC
HELP
MEM
Setup 1/3
Setup 2/3
Setup 3/3
(see following page).
Save only appears if a USB flash drive is plugged in
by scanning the displayed barcode
Enable functions, display extras
Only with database extension or feature KB01:
Manage and import own sequences
with password (see note in this regard below)
Set test sequence parameters: amongst others mea-
suring sequences (standard) (see section 10.3)
Parameters for single measurements and test
sequences (see section 4.1.1 and section 6.2)
Menus for using the Bluetooth interface
(see section 14.4) (only with feature M01)
To submenu for selecting and setting up a printer
(see page 14)
Query software/hardware version, serial no.,
Calibration data, memory occupancy, user’s manual *
* QR code with link to current operating instructions on the web
