Gossen MetraWatt SECUTEST PRO User Manual

62 GMC-I Messtechnik GmbH
Classification Parameter – VDE 0701-0702-EDV
1
These parameters must be entered manually if they’re not automatically detected,
or if they’re detected incorrectly.
2
The limit value for protective conductor resistance is determined on the basis of
length and cross-section. Data remain in memory until a new entry is made.
Classification Parameter – VDE 0701-0702-VLTG
1
These parameters must be entered manually if they’re not automatically detected,
or if they’re detected incorrectly.
2
The limit value for protective conductor resistance is determined on the basis of
length and cross-section (length only in the case of EL1). Data remain in memory
until a new entry is made.
Classification Parameter – VDE 0701-0702-PRCD
1
These parameters must be entered manually if they’re not automatically detected,
or if they’re detected incorrectly.
2
The limit value for protective conductor resistance is determined on the basis of
length and cross-section. Data remain in memory until a new entry is made.
3
New classification parameter “PRCD type” (as of firmware V1.7.0)
(only displayed if “Standard
VDE 0701-0702-PRCD” parameter is selected):
– PRCD (standard):
For the testing of simple circuit breaker safety adapters in
which the protective conductor is permanently connected.
– PRCD (SPE):
(SPE = switched protective earth) for testing PRCDs in which
the protective conductor is only connected in switched-on
condition.
– PRCD-S (SPE):
For testing type PRCD-S circuit breaker safety adapters.
– PRCD-K (SPE):
For testing type PRCD-K circuit breaker safety adapters.
Note
The standard or standard variant associated with the
respective selector switch position corresponds to the
default setting.
Ax means that standard variant VDE 0701-0702-PRCD
can be selected in each of the preset switch positions.
Note
For more information on the testing of single-phase and
3-phase type S and K PRCDs by simulating faults see
PROFITEST PRCD test adapter on our website.
Note
Testing of PRCDs (test sequences and time to trip) is only
possible for the DUTs with a nominal voltage of 230 V.
Parameter Setting Options / Meaning
1/2
Standard VDE 0701-0702, see table below
VDE 0701-0702-EDV
VDE 0701-0702-VLTG, see table below
VDE 0701-0702-PRCD, see table below
IEC 62353, see table below
IEC 60974-4, see table below
Protection class
1, 2
PCI, PCII, PCI+II, PCI+III, PCII+III, PCI+II+III
Connection type
1, 2
Test socket
Permanent connection
Adapter: AT16/32
Adapter: AT3-Adapter (feature I01)
2/2
Measurement type (MA)
1
Active
Auto-detection Connection & PC & MT
Connection & PC
Connection & MT
Connection only
PC & measurement type
Protection class only (PC)
Measurement type only (MT)
Disabled: No auto-detection:
all classification parameters such as connection, protection
category and measurement type must be entered manually.
Parameter Setting Options / Meaning
1/2
Standard VDE 0701-0702, see table below
VDE 0701-0702-EDV, see previous table
VDE 0701-0702-VLTG
VDE 0701-0702-PRCD, see following table
IEC 62353, see table below
IEC 60974-4, see table below
Protection class
1, 2
PCI
Connection type
1, 2
Test socket
Adapter: AT3-IIIE
Adapter: EL1 adapter
Adapter: VL2E adapter
2/2
Measurement type (MA)
1
VLTG
2
Auto-detection Connection & PC & MT
Connection & PC
Connection & MT
Connection only
PC & measurement type
Protection class only (PC)
Measurement type only (MT)
Disabled: No auto-detection:
all classification parameters such as connection, protection
category and measurement type must be entered manually.
Parameter Setting Options / Meaning
1/2
Standard VDE 0701-0702, see table below
VDE 0701-0702-EDV, see table above
VDE 0701-0702-VLTG, see previous table
VDE 0701-0702-PRCD
2
IEC 62353, see following table
IEC 60974-4, see table below
Protection class
1, 2
PCI, PCI+II
Connection type
1, 2
Test socket
2/2
Measurement type (MA)
1
PRCD
3
PRCD type
3
PRCD (standard)
PRCD (SPE)
PRCD-S (SPE)
PRCD-K (SPE)
Auto-detection Connection & PC & MT
Connection & PC
Connection & MT
Connection only
PC & measurement type
Protection class only (PC)
Measurement type only (MT)
Disabled: No auto-detection:
all classification parameters such as connection, protection
category and measurement type must be entered manually.
