Classification Parameter – IEC 62353
1
These parameters must be entered manually if they’re not automatically detected,
or if they’re detected incorrectly.
Classification Parameter – IEC 60974-4
1
These parameters must be entered manually if they’re not automatically detected,
or if they’re detected incorrectly.
The limit values in the test instrument are set in accor-
dance with IEC 60974-4:2016 status as of firmware ver-
sion 2.1.0.
Parameter Setting Options / Meaning
1/2
Standard VDE 0701-0702, see table below
VDE 0701-0702-EDV, see table above
VDE 0701-0702-VLTG, see table above
VDE 0701-0702-PRCD, see previous table
IEC 62353
IEC 60974-4, see following table
Protection class
1
PCI, PCII or PCI+II
Connection type
1
Test socket
Permanent connection
Adapter: AT16/32-DI adap.
Adapter: AT3-Adapter
Permanent connection: P1+P2 (only with feature H01)
2/2
Measurement type (MA)
1
Passive
Active
Applied parts Applied parts: none, B, BF, CF or combinations
Type B (body): Devices of this type are suitable for both
internal and external patient applications, except for use
in direct proximity to the heart.
The following protection categories are permissible:
I, II, III or devices with internal electrical power supply.
Type BF (body float): Same as type B, but with type F in-
sulated applied parts.
Type CF (cardiac float) Devices of this type are suitable
for use directly at the heart. The applied part may not be
grounded.
The following protection categories are permissible:
I, II or devices with internal electrical power supply.
Auto-detection Connection & PC & MT
Connection & PC
Connection & MT
Connection only
PC & measurement type
Protection class only (PC)
Measurement type only (MT)
Disabled: No auto-detection:
all classification parameters such as connection, protection
category and measurement type must be entered manually.
Parameter Setting Options / Meaning
1/2
Standard VDE 0701-0702, see table below
VDE 0701-0702-EDV, see table above
VDE 0701-0702-VLTG, see table above
VDE 0701-0702-PRCD, see table above
IEC 62353, see previous table
IEC 60974-4
Protection class
1
PCI, PCII or PCI+II
Connection type
1
Test socket
Permanent connection
Adapter: AT16/32-DI adap.
Adapter: AT3-Adapter
2/2
Measurement type (MA)
1
Active
Voltage, rating plate Voltage from rating plate, U(R) RMS
(RMS limit value, variably adjustable)
or open-circuit voltage U0 DC (limit value = 113 V DC)
Auto-detection Connection & PC & MT
Connection & PC
Connection & MT
Connection only
PC & measurement type
Protection class only (PC)
Measurement type only (MT)
Disabled: No auto-detection:
all classification parameters such as connection, protection
category and measurement type must be entered manually.
