66 GMC-I Messtechnik GmbH
❑ Setting Measurement Duration for Individual Test Steps
Testing time for the respective measurement can be influenced
with these parameters. If a test step for a single measurement is
involved, the entire test step has a duration of the time entered in
seconds. If a test step for a multiple measurement is involved, the
measurement duration for each measuring point is influenced.
If 0 seconds is selected, continuous measurement is conducted
which can only be ended by the inspector by pressing a key.
1
In the case of test sequence VDE 0701-0702-PRCD with a setting of
“PRCD type: PRCD (SPE)”, measurement duration cannot be influenced.
The measurement duration which has been set here only affects the RPE measure-
ment with PRCD types “PRCD (standard)” and “PRCD-S (SPE)”.
Parameter
(as of FW1.5.0)
Meaning
RPE measurement
duration
1
Set testing time for the protective conductor resistance
measurement (0 to 60 seconds)
IPE measurement duration Set testing time for the protective conductor current mea-
surement (0 to 60 seconds)
IE measurement duration Set testing time for the device leakage current measure-
ment (0 to 60 seconds)
Parameter
(as of FW1.8.0)
Meaning
IT measurement duration Set testing time for touch current measurement
(0 to 60 seconds)
IT PC II measurement
duration
(for IEC 60974 only) Set testing time for touch current
measurement at PC II parts (with the exception of welding
outputs) (0 to 60 seconds)
RINS PC II measurement
duration
Set testing time for RINS measurements and PC II parts
(0 to 60 seconds)
