Parts
3A0420ZAF 59
55 24E872 BRACKET, hopper
2 222222
56 262479 HOPPER, blue
1 111111
57 262480 HOPPER, green
1 111111
58 116704 ADAPTER, fitting
2 222222
59 14V421 TUBE, recirculation
2 222222
60 H52506 HOSE, circulation, 6 ft
2 222222
H52510 HOSE, circulation, 10 ft 2
2
61 16D376 FITTING, intake, with plug 2 222222
61a 198292 Plug, 3/8 in.
2 222222
62 111192 SCREW, serrated flange head, 3/8-16
4 444444
64 - - - - - VALVE, safety See page 81, for detail
65 262482 STRAINER, hopper, 7 gallon
2 222222
66 15T468 LABEL, warning 2 222222
67 16E336 GUIDE, quick start (not shown) 111111111
68 114958 STRAP, tie (not shown) 10 10 10 10 10 10 10 10 10
69 16F615 TOOL, wrench, Xtreme 111111111
70 16F359 Label, warning 111111111
71 16F536 LABEL, arrow 111111111
72 262392 PUMP, solvent (see pg 74 for details)
1111111
73 104984 FITTING, tee, 1/4 in. npt
1111111
74 156971 FITTING, nipple, 1/4 in. npt
1111111
75 H42506 HOSE, 4500 psi, 6 ft 1111111
76 214037 VALVE, ball, 1/4 in.
1111111
77 205447 COUPLING, hose
1111111
78 061132 HOSE, primer 1111111
79 24F126 MODULE, air controls
1111111
80 16F537 HOSE, air line, 6 ft (1.8 m)
1111111
83 H75005 HOSE (heater to manifold)
2222222
84 166590 FITTING, elbow
22 2
85 245863 HEATER, 240V, hazardous locations 22 2
245869 HEATER, fluid, 240V, nonhazardous locations 2 2
245870 HEATER, fluid, 480V, nonhazardous locations 22
86 185065 ADAPTER, cable
22 2
89 16G819 TOOL, wrench, Xtreme 111111111
90 16J688 PLUG, hole 1 1
92 126786 TOOL, restrictor 111111111
93 273096 KIT, junction box, 240 V, nonhazardous
1 1
273101 KIT, junction box, 480 V, nonhazardous 11
94 17P846 BRACKET, junction box
1 111
95 273093 PUMP, heated-hose, circ.
11 1
96 17P092 PLATE, pump mount 11 1
97 110755 WASHER, flat, 1/4 in.
66 6
98 100016 WASHER, lock, 1/4 in.
66 6
99 104429 SCREW, 1/4-20 x 2.25 in. 66 6
100 26C426 MONITOR, PressureTrak (see pg 77 for details)
11 1
Ref. Part Description
Quantity
xxxxx1 xxxxx2 xxxxx3 xxxxx4 xxxxx5 xxxxx6 xxxxx7 xxxxx8 xxxxx9
