UCM630xA Series User Manual
Version 1.0.9.10
 PPPoE
Once selected, users need specify the Account ID, Password and
Service Name for PPPoE.
Host Name
Specifies the name of the client. This field is optional but may be required
by Internet Service Providers.
Vendor Class ID
Used by clients and servers to exchange vendor class ID.
Account ID
Enter the PPPoE account ID.
Password
Enter the PPPoE Password.
Service Name
Enter the PPPoE Service Name.
Advanced Setting
Layer 3 QoS
Define the Layer 3 QoS parameter. This value is used for IP Precedence,
Diff-Serv or MPLS. Valid range is 0-63.
Layer 3 QoS For RTP
Assign the priority value of the Layer 3 QoS for RTP packets.
Valid range is 0 -63.
Layer 3 QoS For SIP
Assign the priority value of the Layer 3 QoS for SIP packets.
Valid range is 0 -63.
Layer 2 QoS Tag
Assign the VLAN Tag of the Layer 2 QoS packets.
Valid range is 0 -4095.
Layer 2 QoS Priority Value
Assign the priority value of the Layer 2 QoS packets.
Valid range is 0-7.
STUN Server
Configure the IP address or Domain name of the STUN server. Only non-
symmetric NAT routers work with STUN.
Keep Alive
Select either to enable or disable Keep Alive.
Keep Alive Interval
Specify how often the phone will send a blank UDP packet to the SIP server
in order to keep the “ping hole” on the NAT router to open. Valid range is
