UCM630xA Series User Manual
Version 1.0.9.10
NAT Traversal
Configure if NAT traversal mechanism is activated.
User Random Port
If set to “Yes”, this parameter will force random generation of both the
local SIP and RTP ports.
General Settings
Call Progress Tones
Configure call progress tones including ring tone, dial tone, second dial
tone, message waiting tone, ring back tone, call waiting tone, busy tone
and reorder tone using the following syntax:
f1=val, f2=val[, c=on1/ off1[- on2/ off2[- on3/ off3]]];
 Frequencies are in Hz and cadence on and off are in 10ms).
 “on” is the period (in ms) of ringing while “off” is the period of silence.
Up to three cadences are supported.
 Please refer to user manual of the SIP devices to be provisioned for
more details
HEADSET Key Mode
Select “Default Mode” or “Toggle Headset/Speaker” for the Headset key.
Please refer to user manual of the SIP devices to be provisioned for more
details.
Table 31: Global Policy Parameters – Contact List
LDAP Phonebook
Source
Select “Manual” or “PBX” as the LDAP configuration source.
 If “Manual” is selected, the LDAP configuration below will be applied to
the SIP end device.
 If “PBX” is selected, the LDAP configuration built-in from UCM630xA
Web GUISystem SettingsLDAP Server will be applied.
Address
Configure the IP address or DNS name of the LDAP server.
Port
Configure the LDAP server port. The default value is 389.
Base DN
This is the location in the directory where the search is requested to begin.
Example:
