UCM630xA Series User Manual
Version 1.0.9.10
The following table summarizes the layout of the LCD menu of UCM630x.
Table 3: LCD Menu Options
View Events
 Critical Events
 Other Events
Device Info
 Hardware: Hardware version number
 Software: Software version number
 P/N: Part number
 WAN MAC: WAN side MAC address
 LAN MAC: LAN side MAC address
 Uptime: System uptime
Network Info
 WAN Mode: DHCP, Static IP, or PPPoE
 WAN IP: IP address
 WAN Subnet Mask
 LAN IP: IP address
 LAN Subnet Mask
Network Menu
 WAN Mode: Select WAN mode as DHCP, Static IP or PPPoE
 Static Route Reset: Select this to reset static route settings.
Factory Menu
 Reboot
 Factory Reset
 LCD Test Patterns
Press DOWN and OK buttons to scroll through and select different LCD
patterns to test. Once a test is done, press the OK button to return to the
previous menu.
 Fan Mode
Select Auto or On.
 LED Test Patterns
All On, All Off, and Blinking are the available options. Selecting Back in the
menu will revert the LED indicators back to their actual status.
 RTC Test Patterns
