Grandstream Networks UCM6302A User Manual

P a g e | 50
UCM630xA Series User Manual
Version 1.0.9.10
Figure 6: UCM6304A Back View
UCM6308A front and back view
Figure 7: UCM6308A Front View
Figure 8: UCM6308A Back View
WAN port
4x FXS ports
4x FXO ports
Power
Heartbeat port
LAN port
Ground
Navigation keys
WAN LED
LAN LED
8x FXS LEDs
8x FXO LEDs
SD card slot
2x USB ports
Heartbeat LED
OK button
Power LED
WAN port
8x FXS ports
8x FXO ports
Power
Heartbeat port
LAN port
Ground

Grandstream Networks UCM6302A Specifications

General

Brand	Grandstream Networks
Model	UCM6302A
Category	PBX
Language	English
