UCM630xA Series User Manual
Version 1.0.9.10
Allow IP
Address From
Enter the DHCP IP Pool starting address. The default setting is 192.168.2.100.
Allow IP
Address To
Enter the DHCP IP Pool ending address.
The default setting is 192.168.2.254.
Default IP
Lease Time
Enter the IP lease time (in seconds). The default setting is 43200.
LAN (when Method is set to "Switch")
IP Method
Select DHCP, Static IP, or PPPoE. The default setting is DHCP.
IP Address
Enter the IP address for static IP settings. The default setting is 192.168.0.160.
Subnet Mask
Enter the subnet mask address for static IP settings. The default setting is 255.255.0.0.
Gateway IP
Enter the gateway IP address for static IP settings. The default setting is 0.0.0.0.
DNS Server 1
Enter the DNS server 1 address for static IP settings.
DNS Server 2
Enter the DNS server 2 address for static IP settings.
Username
Enter the username to connect via PPPoE.
Password
Enter the password to connect via PPPoE.
Layer 2 QoS
802.1Q/VLAN
Tag
Assign the VLAN tag of the layer 2 QoS packets for LAN port. The default value is 0.
Layer 2 QoS
802.1p Priority
Value
Assign the priority value of the layer 2 QoS packets for LAN port. The default value is 0.
LAN 1 / LAN 2 (when Method is set to "Dual")
Default
Interface
If "Dual" is selected as "Method", users will need assign the default interface to be LAN 1
(mapped to UCM6302A WAN port) or LAN 2 (mapped to UCM6302A LAN port) and then
configure network settings for LAN 1/LAN 2. The default interface is LAN 2.
IP Method
Select DHCP, Static IP, or PPPoE. The default setting is DHCP.
