Grandstream Networks UCM6302A User Manual

P a g e | 69
UCM630xA Series User Manual
Version 1.0.9.10
 DHCPv6: Stateful address auto configuration using DHCPv6 protocol.
The default setting is Disabled.
DHCP Prefix
Enter DHCP prefix. (Default is 2001:db8:2:2::)
DHCP
prefixlen
Enter the Prefix length for static settings. Default is 64
DNS Server 1
Enter the DNS server 1 address for static settings. Default is (2001:4860:4860::8888 )
DNS Server 2
Enter the DNS server 2 address for static settings. Default is (2001:4860:4860::8844 )
Allow IP
Address From
Configure starting IP address assigned by the DHCP prefix and DHCP prefixlen.
Allow IP
Address To
Configure the ending IP address assigned by the DHCP Prefix and DHCP prefixlen.
Default IP
Lease Time
Configure the lease time (in second) of the IP address.
LAN (when Method is set to "Switch")
IP Method
Select Auto or Static. The default setting is Auto
IP Address
Enter the IP address for static IP settings.
IP Prefixlen
Enter the Prefix length for static settings. Default is 64
DNS Server 1
Enter the DNS server 1 address for static settings.
DNS Server 2
Enter the DNS server 2 address for static settings.
LAN 1 / LAN 2 (when Method is set to "Dual")
Default
Interface
Users will need assign the default interface to be LAN 1 (mapped to UCM630xA WAN port)
or LAN 2 (mapped to UCM630xA LAN port) and then configure network settings for LAN
1/LAN 2. The default interface is LAN 1.
IP Method
Select Auto or Static. The default setting is Auto
IP Address
Enter the IP address for static IP settings.
