UCM630xA Series User Manual
Version 1.0.9.10
Type
Select the traffic type.
 IN
If selected, users will need specify the network interface "LAN" or "WAN"
(for UCM630xA) for the incoming traffic.
 OUT
Interface
Select the interface to use the Firewall rule.
Service
Select the service type.
 FTP
 SSH
 Telnet
 HTTP
 LDAP
 Custom
If "Custom" is selected, users will need specify Source (IP and port),
Destination (IP and port) and Protocol (TCP, UDP or Both) for the service.
Please note if the source or the destination field is left blank, it will be used
as "Anywhere".
Source IP Address
and Port
Configure a source subnet and port. If set to "Anywhere" or left empty, traffic
from all addresses and ports will be accepted. A single port or a range of ports
can be specified (e.g., 10000, 10000-20000).
Destination IP
Address and Port
Configure a destination subnet and port. If set to "Anywhere" or left empty, traffic
can be sent to all addresses and ports. A single port or a range of ports can be
specified (e.g., 10000, 10000-20000).
Protocol
Select the protocol for the rule to be used.
Save the change and click on "Apply" button. Then submit the configuration by clicking on "Apply Changes" on
the upper right of the web page. The new rule will be listed at the bottom of the page with sequence number,
rule name, action, protocol, type, source, destination, and operation. More operations below:
