Page 18 of 49 S1024.mz-32-V2.1-EN
Transmitter Power
Installing the Battery
Charge the Battery
Battery Removal
Low Voltage Warning
Battery use Timer
The mz-32 HoTT transmitter is normally delivered with a 9000 mAh 1s3p
LiHV battery.
Note
Pay attention when inserting the battery to the correct position and make
sure the contacts are solid. Interruptions of the power supply to the
transmitter during the use of the models can lead to serious danger to
yourself and to other people!
Insert the two connection plugs of the transmitter battery into the battery
connection sockets with the correct polarity. The corresponding symbols are
engraved above the two connection sockets: Red = + Black/Brown = -
The transmitter battery is charged by means of the micro-USB socket on the
back of the transmitter. Further details can be found in the section
"Charging" under "micro USB socket".
Open the battery case cover. Lift the battery and then carefully remove the
plugs of the power cable.
You can charge the battery outside the transmitter. Consult your charger
instructions for proper charging
The supply voltage of the transmitter must be monitored during operation.
If it drops below an adjustable capacity limit which by default is 20%, an
appropriate warning message will continuously sound.
Stop operation of your transmitter and charge the battery!
Attention
As soon as the supply voltage of the transmitter falls below 3.6 V, the
transmitter switches off automatically without further warning.
The battery used time is added each time the transmitter is switched on.
After each charge or battery exchange the timer is reset to "00:00".
However, this only happens if the battery voltage is noticeably higher than
before. By default, the battery service timer as well as the model operating
