GRAUPNER mz-32 HoTT User Manual

Page 7 of 49 S1024.mz-32-V2.1-EN
Technical Data
Transmitter mz-32 HoTT
Frequency band 2404.056 ~ 2474.025 GHz
Modulation FHSS
Transmitting power 100 mW EIRP / Dual Alternating Output
Channels 70 ~ 74
Control functions 32 functions of which 8 can be trimmed
64 digital switch functions
Temperature range -10 - 55 °C / 14 – 130 °F
Antenna
1 linear and 1 circular polarized, with
adjustable angle, integrated antenna
with
1.58 dbi gain.
Operating voltage 3.6 … 4.35V
Power consumption 480 to 1100mA
Dimensions Approx. 210 x 195 x 105mm
8.27 x 7.68 x 4.13in
Weight approx. 1120g/39oz with battery
Note
The technical information of Graupner receivers can be found in the related
receiver system manual or online.
WiFi
Frequency Range
2412 MHz ~ 2474 MHz
Frequency Band
IEEE 802.11 b/g/n HT20
Channels
11
Modulation Type
IEEE 802.11b: DSSS (CCK, DQPSK, DBSK);
IEEE 802.11g: OFDM (64QAM, 16QAM,
QPSK, BPSK); IEEE 802.11n HT20:
OFDM(64QAM, 16QAM, QPSK, BPSK)
Antenna
Omni with 3.0 dBi gain
Bluetooth® 3.0+EDR
Frequency Range
2402 MHz ~ 248- MHz
Modulation Type
GFSK, Pi/4 DQPSK, 8DPSK
Channels
79
Antenna
PCB with 0 dBi gain
