Page 25 of 49 S1024.mz-32-V2.1-EN
1 RF status of the transmitter
2 RF status of the receiver
3 Screen lock on/off
4 USB connection connected/not connected
5 Headphones connected/not connected
6 DSC cable connected/not connected
7 Bluetooth on/off
8 GPS signal available/not available
9 WLAN connected/not connected
10 Data logging on/off
11 Widget and data clear icon
12 Help icon
13 Battery status, tapping switches between % and Volt
Note
All other indications on the display are freely interchangeable and are stored
model-specific.
