GRAUPNER mz-32 HoTT User Manual

Page 19 of 49 S1024.mz-32-V2.1-EN
Switch Transmitter ON
Initial Setup
These two clocks can also be installed as widgets on one of your user widget
decks.
Pressing the front ON / OFF switch for about 1 second switches the mz-32
HoTT transmitter on.
If the transmitter is still in the delivery status or the transmitter was
previously reset to factory settings in the "Info & Update" menu, an almost
self-explanatory wizard starts immediately after the transmitter is switched
on to obtain user settings preferences.
The questions of the first four displays should be selected based on your
personal preferences. Please note that all these settings can be later
changed in the system menu
Tapping the symbol “>“ at the right side of the display switches to the next
display and tapping the symbol “<“ at the left side switches backward to the
last display.
(Fixed Wing Models
(Helicopter Models)
MODE 2 (Throttle left)
Elevator
Elevator
Rudder
Rudder
Full throttle
Motor idle
Querruder
Querruder
Full throttle
Motor idle
Rudder
Rudder
Elevator
Elevator
Aileron
Aileron
Elevator
Elevator
Aileron
Aileron
Full throttle
Motor idle
Rudder
Rudder
Full throttle
Motor idle
Aileron
Aileron
Elevator
Elevator
Rudder
Rudder
MODE 1 (Throttle right)
MODE 3 (Throttle right) MODE 4 (Throttle left)
MODE 2 (Throttle left)
Nick
Nick
Tail rotor
Tail rotor
Motor / Pitch
Motor / Pitch
Roll
Roll
Motor / Pitch
Motor / Pitch
Tail rotor
Tail rotor
Nick
Nick
Roll
Roll
Nick
Nick
Roll
Roll
Motor / Pitch
Motor / Pitch
Tail rotor
Tail rotor
Motor / Pitch
Motor / Pitch
Roll
Roll
Nick
Nick
Tail rotor
Tail rotor
MODE 1 (Throttle right)
MODE 3 (Throttle right) MODE 4 (Throttle left)
Starting the Transmitter
