Page 39 of 49 S1024.mz-32-V2.1-EN
Note
The height of the bar is a measure of the reception level expressed as
logarithmic values with the unit dBm (1mW = 0dBm).
0 dBm corresponds to the two baselines in the above
graph. Consequently, the level is poorer the higher the bar
and vice versa.
The dots above the bar mark the worst reception levels
from the opening of the "RF Status" display. A reset of
these points is therefore possible by exiting and recalling
this display.
In addition to the graphic display of the reception level,
additional numeric information is provided to the left.
This means:
Value Description
Tx ant.
Quality expressed as a percentage of the signal
packages from the receiver arriving at the transmitter
Tx strength
Quality expressed as a percentage of the signal
packages from the transmitter arriving at the receiver
Tx dBm Level in dBm expressed as the percentage of the
receiver signal arriving at the transmitter
Lost pack. Indicates the number of lost data packets
Rx ant.
Quality expressed as a percentage of the signal
packages from the transmitter arriving at the receiver
Rx strength
Quality expressed as a percentage of the signal
packages from the receiver arriving at the transmitter
Rx dBm Level in dBm expressed as the percentage of the
transmitter signal arriving at the receiver
Voltage actual operating voltage of the power supply of the
receiving system
